Model Number | KAIOU3220UV flatbed printer |
Print Head | 8 pcs Ricoh G6 |
Printing area | 3200*2000mm |
Print Direction | Bi-Direction/Uni-Direction |
Ink Type | UV Ink |
Print Speed | Standard mode:45m/h 6pass |
High-precision mode: 30m/h 8pass | |
Ink Color | CMYK+W+V |
RIP Software | Photoprint |
Ink System | CISS With White Ink Circulation System |
Media Thickness | Max 350 mm |
Resolution | 1200Dpi*1200Dpi |
Power | 6500W |
Power Requrement | 208V-220V,50HZ/60HZ 32A |
Warranty | 1 Year Warranty(except printhead),Lifetime Maintenance |
Printer Dimension | 5480*2780*1530(mm), N.W:1800KG |
Packing Size | 2300*5800*1920(mm), G.W:3600KG |
| Specification | KAIOU 2513 UV Flatbed Printer |
|---|---|
| Printing Area | 2500 × 1300mm |
| Printhead | Ricoh Gen6 Industrial Printhead |
| Maximum Speed | Up to 45㎡/h; 35㎡/h; 29㎡/h |
| Maximum Printing Height | 100mm |
| Ink Configuration | CMYK + White + Varnish |
| Resolution | Up to 2880 dpi |
| Positioning System | CCD Vision Positioning System |
| Printing Technology | UV LED Inkjet Printing |
| Materials | Ceramic, Acrylic, Wood, Glass, Metal, Crystal, Leather, PVC, ABS, etc. |
| Application | Industrial Custom Printing, Decoration, Signage, Manufacturing |
| Parameter | Details |
|---|---|
| Model | KO-1612UV |
| Print Size | 1600mm × 1200mm |
| Visual System | 1200DPI Industrial Line Array Camera |
| Printheads | Ricoh G5i/G6, Epson i3200 (2-8 pcs, customizable) |
| Resolution | Up to 1800dpi |
| Max Print Height | 150mm |
| Power Supply | 200-240V AC, Single Phase, 50/60Hz |
| Machine Size | 3240 × 2018 × 2018mm |
| Weight | 950kg |
| Printhead Model | Epson XP600 |
| Color Mode | CMYK |
| Print Area | 21x24cm |
| Resolution | 8-pass |
| Ink Bottle Capacity | 300ml*5 |
| Data Transfer | Gigabit Ethernet |
| Product Dimensions | 56*37*38.5cm |
| Net/Gross Weight | 33kg/46kg |
| Voltage | 110~220V (optional) |
| Operating Software | Northern Printing + Sharp Printing |
| Management Method | H5,supports multiple languages |
| Printing application | fridge magnets, photo cards, souvenir coins, golf balls, badges |
| Model | KO-1612 |
| Application | phone cases, keychains, mugs, badge, token, artwork, decorative panels, custom packaging for luxury items, promotional items, golf ball, pen, USB drivers, Lipstick tubes, cosmetic boxes, toy Rubik's Cubes, leather etc. |
| Printhead | Ricoh G5i/ Toshiba CE4M/ Epson i3200 printhead |
| Print width | 1600*1200mm |
| Print height | 0~100mm |
| Speed | Up to 2000 coins/hour |
| Color | CMYK+W+varnish; support up to 8 colors+varnish |
| Software | RIIN |
| Ink Droplet Size | 3.5PL; 7-21PL |
| Printer size | 320*210*140cm |
| Printer weight | 720kg |
| Package | Wooden |
| Model | KO-1260 |
| Application | phone cases, keychains, mugs, badge, token, artwork, decorative panels, custom packaging for luxury items, promotional items, golf ball, pen, USB drivers, Lipstick tubes, cosmetic boxes, toy Rubik's Cubes, leather etc. |
| Printhead | Toshiba CE4M*2-6 |
| Print width | 1200*600mm |
| Print height | 0~100mm |
| Speed | Max 13㎡/h |
| Color | CMYK+W+varnish |
| Software | PRINTFACTORY |
| Ink Droplet Size | 5-35PL |
| Printer size | 257*111*134cm |
| Print weight | 380kg |
| Package | Wooden |
