Product Model | 1700G |
Printhead | 1pc Epson DX5/DX7/4720 |
Ink Type | Eco solvent ink |
Print mode | Draft 3pass 21㎡/h |
Standard 4pass 16㎡/h | |
Quality 6pass 13㎡/h | |
Ink Supply System | Continuously automatic ink supply |
Width | 1750mm |
Maximum Print Width | 1700mm |
Media | Vinyl,Flex,Backlit,Window film,etc |
Auto Media Feeding System | Auto Feeding and Take up System |
Auto Cleaning System | Positive Cleaning Anti-clogged Flash Function |
Pre-heating &Drying System | Panel Heating: Temperature controller 30C°adjustable |
Output Drying: 10~60C°adjustable External Drying Fan Internal Radiating Fan | |
Computer System | WindowsXP\VISTA\7\8 |
Print interface | Network interface/USB2.0 |
Printhead Height | 2-5mm Distance to the printing platform,Adjustable |
RIP Software | Maintop(standard)/ UitraPrint, Photoprint(optional) |
Input Power | AC220V(±10%),50HZ |
Power | Max 1200W; Operating Power: 500W |
Operation Environment | Temperature:20-30℃Humidity:50%-65% |
Machine Dimension/NW | L2630×W850×H1500mm 220kg |
Package Dimension/GW | L2740×W830×H680mm 270kg |
| Product Model | KO-1604/KO1804 |
| Printhead | 1-4pc Epson i3200 |
| Ink Type | Eco solvent/waterbased/sublimation ink |
| Print mode | Max 80 ㎡/h |
| Ink Supply System | Continuously automatic ink supply |
| Width | 1600/1800mm |
| Maximum Print Width | 1550/1800mm |
| Media | Widely used for various sign and graphics printing, window graphics, wall decor, vehicle graphics wraps, poster, banners, stickers, labels, Vinyl,Flex,Backlit,Window film, |
| Auto Media Feeding System | Auto Feeding and Take up System |
| Auto Cleaning System | Automatic lifting cleaning mechanism |
| Pre-heating &Drying System | Panel Heating:Temperature controller 30C°adjustable |
| Output Drying: 10~60C°adjustable External Drying Fan Internal Radiating Fan | |
| Computer System | Windows 7/10 64bit |
| Print interface | Gigabit Ethernet port |
| Printhead Height | 2-5mm Distance to the printing platform,Adjustable |
| RIP Software | Maintop(standard)/ Photoprint(optional) |
| Input Power | AC220V(±10%),50HZ |
| Power | 5000W |
| Operation Environment | Temperature:15-30℃;Humidity:40%-60% |
| Machine Dimension/NW | 2700*750*1600mm 250kg |
| Package Dimension/GW | 3300*850*80mm 300kg |
| Product Model | 1802C |
| Printhead | 2pcs Epson DX5/DX7/4720/XP600 |
| Ink Type | Eco solvent ink |
| Print mode | Draft 3pass 36㎡/h |
| Standard 4pass 30㎡/h | |
| Quality 6pass 22㎡/h | |
| Ink Supply System | Continuously automatic ink supply |
| Width | 1850mm |
| Maximum Print Width | 1800mm |
| Media | Widely used for various sign and graphics printing, window graphics, wall decor, vehicle graphics wraps, poster, banners, stickers, labels, Vinyl,Flex,Backlit,Window film, |
| Auto Media Feeding System | Auto Feeding and Take up System |
| Auto Cleaning System | Positive Cleaning Anti-clogged Flash Function |
| Pre-heating &Drying System | Panel Heating:Temperature controller 30C°adjustable |
| Output Drying: 10~60C°adjustable External Drying Fan Internal Radiating Fan | |
| Computer System | WindowsXP/ VISTA/7/8 |
| Print interface | Network interface/USB2.0 |
| Printhead Height | 2-5mm Distance to the printing platform,Adjustable |
| RIP Software | Maintop(standard)/ UitraPrint, Photoprint(optional) |
| Input Power | AC220V(±10%),50HZ |
| Power | Max 1200W; Operating Power: 500W |
| Operation Environment | Temperature:20-30℃ Humidity:50%-65% |
| Machine Dimension/NW | L2630×W850×H1500mm 220kg |
| Package Dimension/GW | L2740×W830×H680mm 270kg |
